CNC Horizontal & Vertical Turning
For nearly 7 decades Richardson Manufacturing Company has specialized in high-precision horizontal and vertical turning operations. We routinely hold tolerances of +/- .0005” with the capability to handle workpieces up to 128” diameter and weighing up to 20,000 lbs. We pride ourselves on our ingenuity in workholding, cutting tool application, and process development. Our engineers utilize state-of-the-art equipment to produce parts efficiently with
consistent quality.

We work diligently with our customers to meet cost, quality, and delivery requirements. Common applications include machining of ductile iron castings and steel forgings and castings.

  • 1
  • 2
  • 3
  • 4
  • Diff-Carrier-Webster-Bennett-Turning-(2)
  • Pg.-7-Replace-Bottom-Right-Pic.
  • 5
  • 10
  • 13
  • turning_4
  • turning_13
  • turning7
  • wb_trade_magazine_pic3







Turning Capacity
  CNC Vertical Turning Capacity CNC Horizontal Turning Capacity
Tolerances ±.0005” / ± 0.0127 mm ±.0005” / ± 0.0127 mm
Workholding
  • Three and Four-jaw Hydraulic chucks
  • Custom fixtures and chucks designed and built in house as needed
  • Custom soft jaws and workholding components
Max. Part Weight 20,000 lbs 20,000 lbs
Table/Chuck
Diameter
120 in / 3,048 mm 48 in / 1,219.2 mm
X Axis Travel 90 in / 2,286 mm 27 in / 685.8 mm
Z Axis Travel 59 in / 1,498.6 mm 150 in / 3,810 mm
Distance Between
Centers
  156” / 3962.4 mm
Work Height 110” in / 2794 mm
Swing 128” in / 3251.2 mm 58.27” in / 1,480 mm
